1000 Series Static Shielding Film
Price :
$260.00 – $1,414.00
This transparent metal-in static shielding film is designed to provide a static safe environment for ESD sensitive electronic devices. The film is heat sealable.SCS Static Shielding Film 1000 Series is manufactured from a polyester, metal, polyethylene laminate. The polyester dielectric in concert with the metal layer provides discharge shielding. The exterior being static dissipative allows electrostatic charges to be removed when grounded.
DOWNLOAD DATA SHEET
This transparent metal-in static shielding film is designed to provide a static safe environment for ESD sensitive electronic devices. The film is heat sealable.SCS Static Shielding Film 1000 Series is manufactured from a polyester, metal, polyethylene laminate. The polyester dielectric in concert with the metal layer provides discharge shielding. The exterior being static dissipative allows electrostatic charges to be removed when grounded.
- Metal-In Film Laminate 0.0028” thick (2.8 mil)
- Protects ESD sensitive contents from electrostatic fields and electrostatic discharges (ESD)
- <10 nJ Discharge Shielding Energy Limit Test per ANSI/ESD STM11.31
- Meets ANSI/ESD S20.20 and ANSI/ESD S541 requirements for ESD shielding packaging inside and outside an ESD
- Protected Area (EPA)
- Dissipative Inner and Outer Surfaces Rs 1 x 104 to <1 x 1011 ohms per ANSI/ESD STM11.11 and Static Control Bag
- ANSI/ESD S11.4 Level 3
- Allows film to be used throughout an ESD Protected Area and grounded when placed on a grounded surface or handled by a grounded operator. Dissipative materials attract less particulate contamination to its surface making it preferred in cleanroom environments.
- Lead-free RoHS 2, REACH and Conflict Minerals Compliant
DOWNLOAD DATA SHEET
| ID | SKU | Uom | Price | Buy | hf:tax:product_cat |
|---|---|---|---|---|---|
| 9456 | 48 x 3000 FT ROLL - 1000R - FILM STATIC SHIELD 1000 SERIES | Roll | $1,186.00 | 1000-series-static-shielding-film static-shielding-film packaging-foil-store-categories static-shielding-bags store-categories root-catalog static-control-store-categories | |
| 9457 | 48 x 300 FT ROLL PLASTIC CORE - 1000R - FILM STATIC SHIELD 1000 SERIES | Roll | $260.00 | 1000-series-static-shielding-film static-shielding-film packaging-foil-store-categories static-shielding-bags store-categories root-catalog static-control-store-categories | |
| 9458 | 60 x 3000 FT ROLL - 1000R - FILM STATIC SHIELD 1000 SERIES | Roll | $1,414.00 | 1000-series-static-shielding-film static-shielding-film packaging-foil-store-categories static-shielding-bags store-categories root-catalog static-control-store-categories | |
| 9455 | 36X3000 FT Roll - FILM1000R - STATIC SHIELD 1000 SERIES | Roll | $838.00 | 1000-series-static-shielding-film static-shielding-film packaging-foil-store-categories static-shielding-bags store-categories root-catalog static-control-store-categories |
| Weight | 1 lbs |
|---|---|
| Packaging | |
| Roll Size | 36 x 3000 FT, 48 x 3000 FT, 48 x 300 FT, 60 x 3000 FT, 36 x 50 LF, 36 x 250 LF, 48 x 250 LF, 48 x 50 LF, 60 x 6000 FT |
